Wc67k-300/3200 Cnc Press Brake,Bending Machine For Aluminum Profiles,Cnc Busbar Bending Machine

Main introduction of CNC press brake (CNC bending machine):

The CNC Synchronized hydraulic press brake is high-efficiency and high-precision in bending sheet metal. The machine is structured in steel plate fabrication with sufficient strength and rigidity. The hydraulic drive prevents the machine from serious overload operation accidents caused by the change of sheet thickness or bad choice of lower die cavity. Additionally, this machine is also featured by the steadiness of work, convenience of operation, and reliable safety. The connecting section to the upper die is provided with compensation device, which compensates the deflection of worktable and slider in bending and guarantees the high work precision. It is equipped with hydraulic servo valves for cylinders balance, freely adjustable ram travels and inching operating criterion convenient for module trial and adjustment. This machine is advanced in technology and reliable in performance, and among the ideal shaping apparatuses. It is widely used in plane, automobile, shipbuilding, and machine with high production efficiency.

Controllers
DA52S

Quick, one page programming

Hotkey navigation

7" VGA colour TFT

Up to 4 axes(Y1, Y2, and 2auxiliary axes).

Crowning controle

Tool/material/product libraryUSB, peripheral interfacing

Advanced y-axis control al-gorithms for closed loop aswell as open loop valves

Sandard Equipments

·Hydraulic valves: Germany BOSCH/ HOERBIGER

·Servo drive and motors: Nanjing ESTUN

·Grating ruler: Germany HEIDENHAIN/ Italy GIVI/Spain FAGOR

·Ball screw and linear guide: Taiwan HIWIN

·Main electrics France SCHNEIDER

·Hydraulic crowing table(under<500T)/mechanical crowing table(up to ≥500T)

·Manual adjustable front support with linear

Main features of our CNC press brake as follows:
1.Overall welded and processed structure.

2.Closed loop control mode composed of electric-hydraulic servo valve and grating ruler for ensure the highest control precision, bending accuracy and re-positioning accuracy are also reach to the highest level. 3.Back gauge mechanism can be multi-axes controlled.

4.Integrated hydraulic system decreases the pipe connections, oil leakage, and increases the stability and overall beautifies.

5.Worktable equipped with hydraulic and mechanical compensation to avoid the deformed upper beam from affecting the quality of the work piece, it is automatically adjusted by the CNC controller with convenience and accuracy.

6.Various brands of CNC controller for options: Delem DA52S,DA53T,DA58T,DA66T,DA69T; CYBELEC CT8, CT12, ETC; ITALY ESA brand. All the controllers with multi-languages.

WC67Y/WC67K Series Technical Parameters

Note: No notice if any changes of the above statistics made.

Wuxi Smart CNC Equipment Group CO.,LTD is a professional manufacturer and exporter in sheet metal machine tools,Wuxi Smart CNC Group their branch company including VISTMAC Machine Manufacturing Co.,Ltd . WUXI SMART CNC has 30 years history in sheet metal working machinery manufacture and export experience.
SMART CNC has always been manufacturing and distributing CNC Fiber Laser Cutting Machine, CNC press brake, hydraulic shear, plate rolling machine, Pipe Bending Machine as well as other sheet metal processing machine, including 5 major kinds, 20 series and more than 200 specifications. The products manufactured are widely employed in field of Machinery Manufacturing, Metallurgy, Petrifaction, Electrical Power, Wind Power Generation, Aerospace, National defense and military industry, Auto-industry, Railway, Shipbuilding, Natural gas and oil transportation. SMART CNC machines have been exported to more 50 countries and regions.
Capability of company: SMART CNC Group has over 250 employees with 310,000m2 floor space, 120,000 m2 construction spaces, among which 60,000 m2 manufacturing space, 300 sets of processing machines with more than 40 sets of heavy duty precise processing equipment.
Applied field: SMART CNC products are wide used in the field of Machineries, auto-making, vessel manufacturing, petrochemical industry, power supply, metallurgy, aerospace, military defense, railway vehicle, engineering machineries, metal forming machineries, wind power generation, natural gas and oil transportation pipe and construction pipe.
Research and develop capacity: 1 National R&D Center awarded by country, 1 Jiangsu Provincial Research Center for Metal forming engineering, 40 professional engineers, among them 10 senior professionals, 1 Outstanding Science expert of Jiangsu Province, 2 Pro. Senior Engineers, 4 engineering doctors from Xi’an Jiaotong University, 8 Engineering management masters, 20 Engineering masters, SMART CNC are honored as Chinese famous trade mark, National May Day Medal Winner, the one of top 10 self-innovation enterprises awarded by CMTBA, one of top 10 companies of nationwide metal processing innovation capacity, also awarded as most innovative company, advanced technological innovation company, The fourth batch of innovative pilot enterprise awarded by Ministry of Science and Technology.
ISO9001:2008 International quality management system certification, ISO14001:2004 environmental management system certification, OHSAS18001:1999 occupational health and safety management system certification.
CE and TUV
Quality undertaking: We are always devoting ourselves to “Quality First, Customer First” principles and keeping our promises for quality, striving for offering products with excellent quality, and we are very pleased to cooperate with friends from all over the world and always achieving co-development.
