High Efficiency Iron Worker CE Approved Q35Y-25 Hydraulic Iron Worker For Sale

Q35Y Series Hydraulic Iron Worker

1. Overall structure:

This machine adopts hydraulic driving system and they are the latest iron workers in China. Various metal plate, square bar, round bar, angle, channel and joist can be cut, punched and notched on the machine. It is also equipped with a stop device for cutting.

2. Advantage:

● This combined punching and shearing machine has punching & shearing angle & section function etc.

● This machine has light weight , small volume, low noise and high efficiency advantages etc, it is the best equipment of modern machinery manufacturing industry, bridge, electric power, communication etc;

● The best advantage for this machine: simple operation, flexible movement, high cutting efficiency, smooth section without a trace, low failure rate, long service life;

Specification

Model	Q35Y-20	Q35Y-25	Q35Y-30	Q35Y-40
Pressure(Ton)	90	110	140	200
Max.cutting thickness(mm)	20	25	30	40
Plate strength(N/mm2)	≤450	≤450	≤450	≤450
Cutting angle(degree)	8°	8°	8°	8°
Shearing size of one stroke(mm)	20x330 10×480	25x330 16×600	30x355 20×600	35x400 25×700
Ram stroke(mm)	80	80	80	100
Cycles/min(20mm stroke)(mm)	8	6	6	8-25
Throat depth(mm)	355	400	600	600
Punching thickness(mm)	20	25	26	35
Max.Punching diameter(mm)	30	35	38	41
Power of main motor(kw)	5.5	7.5	11	15
Overall dimensions(L*W*H)mm	1860x800x1900mm	2355x960x2090mm	2680x1040x2300mm	2850x1300x2400mm
Weight of machine(kg)	2500	4500	6800	9500

Wuxi Smart CNC Equipment Group CO.,LTD is a professional manufacturer and exporter in sheet metal machine tools,Wuxi Smart CNC Group their branch company including VISTMAC Machine Manufacturing Co.,Ltd . WUXI SMART CNC has 30 years history in sheet metal working machinery manufacture and export experience.
SMART CNC has always been manufacturing and distributing CNC Fiber Laser Cutting Machine, CNC press brake, hydraulic shear, plate rolling machine, Pipe Bending Machine as well as other sheet metal processing machine, including 5 major kinds, 20 series and more than 200 specifications. The products manufactured are widely employed in field of Machinery Manufacturing, Metallurgy, Petrifaction, Electrical Power, Wind Power Generation, Aerospace, National defense and military industry, Auto-industry, Railway, Shipbuilding, Natural gas and oil transportation. SMART CNC machines have been exported to more 50 countries and regions.
Capability of company: SMART CNC Group has over 250 employees with 310,000m2 floor space, 120,000 m2 construction spaces, among which 60,000 m2 manufacturing space, 300 sets of processing machines with more than 40 sets of heavy duty precise processing equipment.
Applied field: SMART CNC products are wide used in the field of Machineries, auto-making, vessel manufacturing, petrochemical industry, power supply, metallurgy, aerospace, military defense, railway vehicle, engineering machineries, metal forming machineries, wind power generation, natural gas and oil transportation pipe and construction pipe.
Research and develop capacity: 1 National R&D Center awarded by country, 1 Jiangsu Provincial Research Center for Metal forming engineering, 40 professional engineers, among them 10 senior professionals, 1 Outstanding Science expert of Jiangsu Province, 2 Pro. Senior Engineers, 4 engineering doctors from Xi’an Jiaotong University, 8 Engineering management masters, 20 Engineering masters, SMART CNC are honored as Chinese famous trade mark, National May Day Medal Winner, the one of top 10 self-innovation enterprises awarded by CMTBA, one of top 10 companies of nationwide metal processing innovation capacity, also awarded as most innovative company, advanced technological innovation company, The fourth batch of innovative pilot enterprise awarded by Ministry of Science and Technology.
ISO9001:2008 International quality management system certification, ISO14001:2004 environmental management system certification, OHSAS18001:1999 occupational health and safety management system certification.
CE and TUV
Quality undertaking: We are always devoting ourselves to “Quality First, Customer First” principles and keeping our promises for quality, striving for offering products with excellent quality, and we are very pleased to cooperate with friends from all over the world and always achieving co-development.
