Fiber laser cutting machine adopting world famous Germany IPG fiber
laser source and Raycus laser source,Raytools cutting head and
dynamic focus system, it can cut and punch different kinds of metal
material with high precision and high speed. Since laser is
transmitted by fiber , it is no need to maintenance or adjusts the
laser optical path , it greatly reduces the machines fault rate and
prolongs the working life. Large format cutting area meets the
demands of various kinds of metal processing .
It is widely used for carbon steel, stainless steel, aluminum and
other metal materials cutting and forming, with high speed, high
precision, high efficiency, cost-effective and energy saving. It is
the first choice of the metal processing industry.
1. Designed with industrial heavy-duty steel structure, the
numerical control five-sided processing center can be shaped in the
first time, and can be used for a long time through numerical
control low-temperature annealing to ensure the strength and
stability of the machine.
2. Use high-precision ball screw or high-precision grinding rack,
and import high-precision linear guide with high precision, so as
to ensure long processing time and accuracy.
3. Adopt double drive ac servo drive motor, with stronger torque,
faster and more stable running speed.
4. Adopt imported laser lenses, with smaller focusing spots, more
fine cutting lines, higher working efficiency and better processing
quality.
5. Optical fiber transmission and flexible processing can achieve
equal quality cutting at any point.
Metal stainless steel plate laser cutting machine 1000w
The Max of 1000w can be cut 4mm
The Max of 2000w can be cut 10mm
The Max of 3000w can cut 12mm
Description of type configuration of shandong hongguang laser
cutting machine:
The itinerary is 1500*3000mm, 1500*4000mm, 1500*6000mm,
2000*4000mm, and 2000*6000mm (optional and customizable).
Power: 300w, 500w, 800w, 1000w, 1500w, 2000w, 3000w, 6000w
(optional).
Optional parts: exchange platform, large enclosure.
| Fiber Laser Cutting Machine Technical Parameters |
| Laser Type | Fiber laser |
| Laser Brand | IPG / Raycus |
| Laser Power | 500W (750W / 1000W /2000W/3000W/4000W optional) |
| Working area | 1500mmX3000mm 1300x2500mm 2000*4000mm Optional |
| Working Table | Fixed Working Table |
| Control System | PMAC full-closed loop servo control |
| Driving Mode | Double gear rack driving |
| Positioning Accuracy | 0.05mm |
| Protection System | Enclosure protection |
| Cutting Head | Precitec / Laser Mech / |
| Power Supply | AC380V ± 5% 50 / 60Hz |
| Total Power | 7KW~11KW |
| Standard Collocation | Metal nesting software, dual-pressure gas route of 3 kind gas sources, dynamic focus, remote controller,
etc. |
| Software | CutMax Laser Cutting Software or PA8000 software, Metal Nesting
Software |
| Supported Format | PLT, DXF, BMP, AI, DST, DWG, etc. |
