    Water Cooling Fiber Laser Cutting Machine 2000×6000mm Exchange Table

    Ask Lasest Price
    Brand Name : SMART CNC
    Model Number : 2000W
    Certification : CE ISO TUV
    Price : Negotiable
    Supply Ability : 50 sets/month
    Delivery Time : 45days
    • Product Details
    • Company Profile

    Water Cooling Fiber Laser Cutting Machine 2000×6000mm Exchange Table

    500W 1000W 2000W 3000W 4000W CNC Metal Steel Carbon Steel Fiber Laser Cutting Machine 2000×6000 Exchange Table
    Product Description

    SML Series CNC Fiber Laser Cutting Machine


    1. Application of gantry structure and integrated cast cross-girder to achieve higher rigidity, stability, shock resistance.

    2. High-performance laser source and stable operating system which make the best cutting effect.

    3. The machine owns perfect cooling system, lubrication system and dust removal system, to ensure that it can operate stably, efficiently and durably.

    4. The machine is capable of automatic height adjustment to maintain constant focal length and stable cutting quality.

    5. The machine is used for cutting a variety of metals with excellent and stable cutting quality.

    6. The specialized CAD / CAM automatic programming software and automatic nesting software aim to maximally save raw materials.

    7. Access to the CNC system through Ethernet interface makes communication and remote monitoring possible during the laser cutting process.


    Specification for CNC Fiber Laser Cutting Machine

    DescriptionUnitSML 3015SML 4015SML 4020SML 6020SML 6025
    Max.sheet sizemm3000x15004000x15004000x20006000x20006000x2500
    X-axis strokemm30504050405060506050
    Y-axis strokemm15251525202520252525
    Z-axis strokemm200200200200200
    X, Y axes positioning accuracymm/m0.020.020.020.020.02
    X, Y axes repetition accuracymm±0.02±0.02±0.02±0.02±0.02
    X, Y axes max.speedm/min120120120120120
    Laser powerW500/700/1000/2000/3000/4000/6000
    Machine dimensionm8.8x3.9x2.011x4.5x211x5x215x5.8x25x6.2x2

    Fiber Laser Cutting Machine Technical Parameters
    Laser TypeFiber laser
    Laser BrandIPG / Raycus
    Laser Power500W (750W / 1000W /2000W/3000W/4000W optional)
    Working area1500mmX3000mm 1300x2500mm 2000*4000mm Optional
    Working TableFixed Working Table
    Control SystemPMAC full-closed loop servo control
    Driving ModeDouble gear rack driving
    Positioning Accuracy0.05mm
    Protection SystemEnclosure protection
    Cutting HeadPrecitec / Laser Mech /
    Power SupplyAC380V ± 5% 50 / 60Hz
    Total Power7KW~11KW
    Standard Collocation

    Metal nesting software, dual-pressure

    gas route of 3 kind gas sources, dynamic focus, remote controller, etc.

    SoftwareCutMax Laser Cutting Software or PA8000 software, Metal Nesting Software
    Supported Format

    PLT, DXF, BMP, AI, DST, DWG, etc.
