Good Stability High Speed Power Press Machine 45 Ton CE Certificate

Ask Lasest Price
Brand Name :	SMART CNC
Model Number :	SYA-45
Certification :	CE ISO TUV
Price :	Negotiable
Supply Ability :	50 sets/months
Delivery Time :	20days

Add to Cart

Product Details
Company Profile

Good Stability High Speed Power Press Machine 45 Ton CE Certificate

45 Ton Mechanical Pneumatic Hydraulic Power Press In China, China Supplier Manufacturer Exporter In Punching Press

Features:

aluminum window and door sliding punching press machine

1. Steel welded body, tempering treatment, high rigidity, accuracy and stability;

2. Vertical located crankshaft, compact structure;aluminum window and door sliding punching press machine

3. Lengthened rectangular guideway with a surface of bronze plate;

4. Pneumatic dual balance cylinder, which balances the slide block and punch weight to reduce noise and impact;

5. PLC control and imported safety dual valve;aluminum window and door sliding punching press machine

6. Dry clutch and hydraulic overload protector.aluminum window and door sliding punching press machine

7. CE certificate.aluminum window and door sliding punching press machine

Standard Equipments:

1) Wet clutch

2) PLC

3) Hydraulic overload protecting pump

4) Touch screen

5) Cam controller

6) Die height adjusted motor (SYA-60 and upon models)

7) Auto lubrication system

8) Manual lubrication system

9) Double hand control panel

10) Electronic crankshaft angle indicator

11) Predetermined counter

12) Balance cylinders for slide and upper die

13) Work light

14) Joint for air

15) Joint for miss-feeding

16) Absorbing pads

Optional Equipments:

1) Dry clutch

2) Light curtain

3) Foot pedal

4) Die cushion

5) Inverter

6) Variable speed motor

7) Auto feed shaft

8) Die quick change device

Specification

Specification	Unite	SYA-25			SYA-35		SYA-45		SYA-60
Model		V	H	S	V	H	V	H	V	H
Capacity	Ton	25			35		45		60
Rated tonnage point	mm	3.2	1.6	3.2	3.2	1.6	3.2	1.6	4	2
Speed changing	S.p.m	60-140	130-200	60-120	40-120	110-180	40-100	110-150	35-90	80-120
Stable speed	S.p.m		110	110		85	75		65
Stroke	mm	70	30	80	70	40	80	50	120	60
Die height	mm	195	215	190	220	235	250	265	10	340
Slide adjustment	mm	50		50	55		60		75
Slide area	mm	300×230×50			360×250×50		400×300×60		500×360×70
Bolster area	mm	680×300×70			800×400×70		850×440×80		900×500×80
Shank hole	mm	Ø38.1			Ø38.1		Ø38.1		Ø50
Main motor	Kw.p	3.7×4			3.7×4		5.5×4		5.5×4
Slide adjust device	HP	manual operation
Air pressure	Kg/cm²	6			6		6		6
Presses precision		GB/JIS 1class
Presses dimension	mm	1280×850×2200			1380×900×2400		1600×950×2500		1600×1000×2800
Presses weight	Ton	2.1			3		3.8		5.6
Die cushion capacity	Ton	-			2.3		2.3		3.6
Stroke	mm	-			50		50		70
Die cushion effective area	mm²	-			300×230		300×230		350×300
