160 Ton Automatic Power Press Machine , Mechanical Eccentric Press Machine

JH21 Mechanical Eccentric 160 Ton C Frame Power Press Machine With Single Crank

Standard Execution:

Heavy, one-piece welded steel frame is designed to resist deflection, providing more accurate stampings and longer die life.

Fast-response hydraulic overload relieves the pressure of a tonnage overload in milliseconds, stopping the press immediately and protecting press and dies from damage.

Wet clutch and brake provide long life, very low maintenance, and high performance even at high single-stroking rates.

•JIS I accuracy.v

•Steel welded frame with high rigidity.

•Motor with inverter.

•Combined wet friction clutch.

•Rectangular hexahedral lengthened guide; OCP-315/400 with octahedral lengthened guide.

•Hydraulic overload protector.

•OCP-25/45: manual adjusting, scale indicated.

•OCP-45: optional elec. adjustment with digital display.

•OCP-63 superior: elec. adjustment with digital display.

•Lifting balance cylinder.

•Imported dual solenoid valve.

•Elec.forced grease lubrication.

•Balance cylinder: manual oil lubrication.

•Integrated panel (elec.cam included).

•PLC control of international brand.

•Contactor and button of international brand.

•CE safety specifications

•Optional: air cushion, light curtain, automotive device.

Specification

JH21 series cnc metal plate hole and aluminum punching machine 160ton
Type Item	Unit		JH21-160T
Nominal pressure	KN		1600
Stroke of nominal force	mm		6
Stroke of sliding block	mm		200
Number of strokes	s.p.m		45
Max. Height for die loading	mm		400
Adjustment range for die loading height	mm		100
Distance from slide block centre to the frame	mm		390
Space between columns	mm		720
Bottom size of sliding block	L.R.	mm	700
Bottom size of sliding block	F.B.	mm	580
Hole size for die handle	Dia.	mm	70
Hole size for die handle	Depth	mm	90
Size of worktable	L.R.	mm	1170
	F.B.	mm	760
	Material discharge hole size	mm	180
	Thickness	mm	160
Distance from worktable to ground	mm		900
Power of motor	KW		15
	F.B.	mm	2325
	L.R.	mm	1450
	Height	mm	3250
Total weight	KG		12800
